Multi-Energy-Harvesting Device To Push IoT Development

Researchers from the University of Oulu in Finland have found that a mineral with the perovskite crystal structure has the right properties to extract energy from multiple sources at the same time.

energyimageee

Perovskites are a family of minerals, many of which have shown promise for harvesting one or two types of energy at a time—but not simultaneously. One family member may be good for solar cells, with the right properties for efficiently converting solar energy into electricity. Meanwhile, another is adept at harnessing energy from changes in temperature and pressure, which can arise from motion, making them so-called pyroelectric and piezoelectric materials, respectively.

Sometimes, however, just one type of energy isn’t enough. A given form of energy isn’t always available—maybe it’s cloudy or you’re in a meeting and can’t get up to move around. Other researchers have developed devices that can harness multiple forms of energy, but they require multiple materials, adding bulk to what’s supposed to be a small and portable device.

This week in Applied Physics Letters Yang Bai and his colleagues at the University of Oulu explain their research on a specific type of perovskite called KBNNO, which may be able to harness many forms of energy. Like all perovskites, KBNNO is a ferroelectric material, filled with tiny electric dipoles analogous to tiny compass needles in a magnet.

When ferroelectric materials like KBNNO undergo changes in temperature, their dipoles misalign, which induces an electric current. Electric charge also accumulates according to the direction the dipoles point. Deforming the material causes certain regions to attract or repel charges, again generating a current.

Previous researchers have studied KBNNO’s photovoltaic and general ferroelectric properties, but they did so at temperatures a couple hundred degrees below freezing, and they didn’t focus on properties related to temperature or pressure. The new study represents the first time anyone has evaluated all of these properties at once above room temperature, Bai said.

The experiments showed that while KBNNO is reasonably good at generating electricity from heat and pressure, it isn’t quite as good as other perovskites. Perhaps the most promising finding, however, is that the researchers can modify the composition of KBNNO to improve its pyroelectric and piezoelectric properties. “It is possible that all these properties can be tuned to a maximum point,” said Bai, who, with his colleagues, is already exploring such an improved material by preparing KBNNO with sodium.

Within the next year, Bai said, he hopes to build a prototype multi-energy-harvesting device. The fabrication process is straightforward, so commercialization could come in just a few years once researchers identify the best material.

“This will push the development of the Internet of Things and smart cities, where power-consuming sensors and devices can be energy sustainable,” he said.

This kind of material would likely supplement the batteries on your devices, improving energy efficiency and reducing how often you need to recharge. One day, Bai said, multi-energy harvesting may mean you won’t have to plug in your gadgets anymore. Batteries for small devices may even become obsolete.

More information: Phys.org
