100GHz test capabilities make debut at EuMW 2018

High volume testing of semiconductor devices up to 100 GHz and beyond will be announced by Presto Engineering at European Microwave Week, in Madrid (23-28 September). Applications that use GHz frequencies, such as millimeter wavelengths (MMW), are increasing rapidly and thus driving the need for high volume device testing.

For example, Internet over satellite connections, car ADAS systems, and other high-speed, data transfer solutions with a projected volume of more than a billion units by 2020.

“Commercial test equipment does not test much about 50GHz,” explained Cédric Mayor, Presto’s COO. “The current method used by most customers is in-house bench testing by hand which is slow and expensive. This is because testing equipment above 50 GHz becomes increasingly expensive as the frequency increases as it is non-standard. To solve this problem, we have created custom interfaces that step the test frequencies down into the range that commercial testers operate in. This enables us to provide a cost-effective testing service for ultra-high frequency or MMW devices and builds on our existing services for high frequency device testing.”

Another challenge of MMW devices is that the substrate used is often much more brittle than the usual CMOS, such as Gallium Arsenide or Gallium Nitride. As a result, the wafers are much more susceptible to breakage in transit and handling.

To reduce the possibility of breakage, they are usually cut into quadrants once manufactured. A broken quadrant means fewer damaged parts compared to a whole broken wafer.

However, the standard handling and test equipment is designed for circular wafers so Presto has developed its own quadrant handling adapters for its test equipment.

On top of this, it is also key to be able to maintain a good correlation during the test and during the self-heating of the pulsed test methods, where continuous wave measurement is normally used.

In this case, all the fixturing has to be able to control temperature and heat dissipation as well as include RF systematic error compensation for the measurements and maintain the correct reproducibility during production.

“Testing at these high MMW frequencies also introduces RF issues that are not significant at lower frequencies,” added Cédric Mayor. “Connectors and even tracks can affect the impedance or act as antennae so that the test platform and regime have to be designed to allow for this, based on our years of experience in RF testing. This includes ensuring that Design for Test is incorporated into the devices, especially as access to RF signals is complicated by the integration of antenna, especially when we have to deal with phase arrays or multiple antenna products. This places limitations on the probe card’s physical design that need to be overcome by careful engineering design of the hardware. These issues also impact packaging options such that standard packages are not always appropriate, so we help customers select the optimal packaging such as stack-die, multi-die and even custom solutions to ensure the optimal performance.”

Among MMW applications already implemented or under consideration are short range wireless backhaul, connecting small cell wireless; data center interconnect (DCI) for cloud servers; radar, primarily automotive; body scanners for airport security; chip-to-chip communications on printed circuit boards where even short runs of wires or cables attenuate signals at these frequencies; and wireless communication protocols, such as 5G cellular, WiGig (802.11ad) and Wireless HD.
