Non-hydraulic steering module test simulator designed for automotive OEMs

0

The new non-hydraulic Steering Module Test Simulator (SMTS) from MB Dynamics has been announced. The SMTS is used by automotive, autonomous, construction and off-highway vehicle OEMs and their associated steering suppliers.

It is used for accurate, reliable and repeatable in-laboratory simulations of driver, road and vehicle inputs and their associated effects on steering system performance and annoying noises.

The test benches may be used to effectively detect the root causes of airborne and structure-borne noises, known as rack rattle, clatter, reversal clunk, zipper and running noises, in columns, gears, I-shafts, column EPS and rack EPS units.

The system may also be used to help meet both objective and subjective NVH performance metrics; accurately characterize steering system sensitivity and performance; experimentally verify EPS functions; and to achieve other steering system performance goals, over a vehicle’s full warrantied service life.

Non-hydraulic SMTS turnkey system

A typical non-hydraulic SMTS turnkey system from MB Dynamics may include an extremely electrically and acoustically quiet rack load simulator, capable of simulating tie rod forces to 25kN, as well as strokes from 20mm pk-pk to 250mm pk-pk.

Also available are acoustically and electrically quiet driver simulators for inputting and controlling steering wheel position, velocity and/or torque values to columns and I-shafts from 10-150Nm.

Multiple on-board hardware and software features of the SMTS virtually eliminate the cogging, torque and force fluctuations associated with EPS motor pole-passing.

As a result, no new noises or dynamic disturbances are introduced into the test environment, and therefore no masking of the noises or NVH metrics under evaluation occurs.

The incorporation of extremely quiet system components allows for greater ease of troubleshooting, identification, diagnosis, and resolution of the root causes of unwanted noise and other performance issues common to EPS, EPHS, EPAS, MDPS, and HPS steering systems.

A series of PC-based dynamic controllers further incorporate supplied sensors and signal conditioning to acquire angle, displacement, force, acceleration, and torque parameters, as required for multi-axis closed-loop control.

Additional options include gear fixtures, column stands, a compact mobile measurement system for Road Load Data Acquisition (RLDA); and an NVH test analysis system, for the recording and objective evaluations of noise and vibration parameters. ­ As a non-hydraulic system, the SMTS requires no oil for operation.

Source MB Dynamics
