Powering Medical Devices with a Human Heartbeat

0

Millions of people rely on pacemakers, defibrillators and other life-saving implantable devices powered by batteries that need to be replaced every five to 10 years. Those replacements require surgery which can be costly and create the possibility of complications and infections.

Guess what? The heart’s motion is so powerful that it can recharge devices that save our lives.

At least that’s what new research from Dartmouth College is proving to be true. The team of engineers from the Thayer School of Engineering used a dime-sized invention to prove that the kinetic energy of the heart can be converted into electricity to power a wide range of implantable devices.

“We’re trying to solve the ultimate problem for any implantable biomedical device,” said Dartmouth engineering professor John X.J. Zhang, a lead researcher on the study his team completed alongside clinicians at the University of Texas in San Antonio. “How do you create an effective energy source so the device will do its job during the entire life span of the patient, without the need for surgery to replace the battery?”

“Of equal importance is that the device not interfere with the body’s function,” said Lin Dong, first author on the paper and Dartmouth research associate. “We knew it had to be biocompatible, lightweight, flexible, and low profile, so it not only fits into the current pacemaker structure but is also scalable for future multi-functionality.”

The team’s work proposes modifying pacemakers to harness the kinetic energy of the lead wire that’s attached to the heart, converting it into electricity to continually charge the batteries. The added material is a type of thin polymer piezoelectric film called “PVDF” and, when designed with porous structures — either an array of small buckle beams or a flexible cantilever — it can convert even small mechanical motion to electricity. An added benefit: the same modules could potentially be used as sensors to enable data collection for real-time monitoring of patients.

The results of the three-year study, completed by Dartmouth’s engineering researchers along with clinicians at UT Health San Antonio, were just published in the cover story for Advanced Materials Technologies.

The two remaining years of NIH funding plus time to finish the pre-clinical process and obtain regulatory approval puts a self-charging pacemaker approximately five years out from commercialization, according to Zhang.

“We’ve completed the first round of animal studies with great results which will be published soon,” said Zhang. “There is already a lot of expressed interest from the major medical technology companies, and Andrew Closson, one of the study’s authors working with Lin Dong and an engineering PhD Innovation Program student at Dartmouth, is learning the business and technology transfer skills to be a cohort in moving forward with the entrepreneurial phase of this effort.”

Source Dartmouth College
