1MW water cooled DC electronic load delivered to the US Navy

0

Programmable power products provider, Magna-Power Electronics, has announced the delivery of a 1MW water cooled DC electronic load to the US Navy, which will be used to research, develop, test, and evaluate the operation of Energy Storage Modules (ESMs) in a shipboard environment.

To meet this requirement, Magna-Power delivered ten of its standard 100kW WRx Series MagnaLOAD DC electronic loads, configured in two master-slave sets of 500kW.

The 500kW DC electronic load systems will be part of a real time hardware-in-the-loop (HIL) simulator, which will drive the MagnaLOADs using its high speed analogue input. A digital simulator will be used in place of the actual electric shipboard equipment to conduct model-based simulation of the shipboard electric load. The MagnaLOADs will mimic discharge profile of the ESM, depending on the components under test and the model being simulated.

Given the nature of these tests, which can last for days, Magna-Power designed its MagnaLOAD products for continuous full power operation at 50°C ambient operating temperature and cooling water temperature up to 25°C. Microchannel water cooled heatsinks were designed and are manufactured by Magna-Power, allowing the company deliver power dissipation of 12.5kW per 4U. In addition, Magna-Power’s new patented Active Resistance Technology (US Patent 9,429,629) combines a switched binary matrix of resistances with MOSFETs to deliver features and performance consistent with traditional electronic loads, at a fraction of the price.

The product features a wide operating range, allowing full power to be achieved over the range 50-100% rated voltage in its high power range. A separate low power range enables high current operation at lower voltages.

Ira J. Pitel, President of Magna-Power Electronics, stated: “While a significant engineering undertaking for the company, the result is a brand new product line, three new product series, and a new robust digital control scheme that will be far reaching. As a company, we are very proud to support this program and greatly value the US Navy’s support and cooperation to allow Magna-Power to realize this system.”

This contract was proving ground for Magna-Power’s new distributed DSP digital control platform, MagnaLINK, which paves the way for the company’s future products. This new control platform, available in the MagnaLOAD product line, provides simultaneous high speed high reliability control and measurement aggregation of 40 modules, while operating in a high EMI environment. Furthermore, MagnaLINK provides simultaneous master-slave firmware upgrade, with new product configuration detection and automatic settings reconfiguration.

When fully developed, the ESMs are intended to integrate into the ship’s electrical system and dynamically act as a power source or power sink, depending on the electrical needs of the ship. The MagnaLOAD DC electronic load product line is available now, spanning many air and water cooled models across three product series.

Source Magna-Power
