3.3V surge achieves unmatched surge/silicon area ratio

Semtech Corporation has announced the μClamp 3381P, a single-line, 3.3V surge rated Transient Voltage Suppression (TVS) device for safeguarding industrial and consumer interfaces against transient voltage threats. The μClamp3381P achieves an unmatched surge/silicon area ratio offering 25A (8×20µs) surge immunity in an ultra-small 1.0×0.6mm package.

This surge handling performance is critical for safeguarding industrial data links to reliably transport data in harsh environments, including IoT end nodes, LCD televisions and display banners, tablets, surveillance cameras and optical modules.

Built on Semtech’s industry-leading process technology, the μClamp3381P outperforms current industry solutions with its ESD clamping characteristics. The dynamic resistance of the μClamp3381P is only 0.025Ohms, making the I-V curve characteristics of the device close to that of an ideal diode.

semtechsurgeimage

“The leap in performance achieved by the μClamp3381P is truly a milestone for Semtech and represents a new platform of protection performance we can bring to the design community,” said Rick Hansen, Product Marketing Director for Semtech’s Protection Products. “The μClamp3381P is a breakthrough device that we believe will have wide adoption with our broad customer base.”

Key features of the μClamp3381P

  • transient protection for high-speed data lines to: IEC 61000-4-2 (ESD) ±30kV (air), ±30kV (contact); IEC 61000-4-4 (EFT) 40A (5/50ns); IEC 61000-4-5 (Lightning) 25A (8/20μs)
  • 3.3V working voltage protection
  • high surge capability: 25A (tp=8/20μs) protects 1 I/O line
  • low capacitance (<35 pF line-to-line)
  • small 1.0×0.6×0.5mm package
  • Pb Free and RoHS/WEEE compliant

Datasheets available:

Semtech uclamp3381p datasheet
