ZMDI announces the new ZSPM1513 for core or auxiliary voltages of FPGAs and SoCs for ultra-fast and easy-to-use power solutions

Dresden, Germany – May 18th – ZMD AG (ZMDI), an award-winning global semiconductor company headquartered in Dresden, Germany, and specializing in enabling energy-efficient solutions, has released the ZSPM1513, single–phase, true–digital pulse-width modulator (PWM) power controllers optimized for non-isolated point-of-load (POL) applications. ZMDI offers superior, high-performance solutions for power management, sensing, battery management, automotive ASICs and industrial ASSPs. With over 50 years of industry leadership, ZMDI offers high-quality products and services that have earned their customers’ trust in power management products. ZMDI is introducing the ZSPM1513 to expand its energy-efficient ZSPM15xx True-Digital PWM Controller Family of turnkey smart POL solutions.

ZSPM1513 optimized for core or auxiliary voltages
ZSPM1513 optimized for core or auxiliary voltages

The ZSPM1513 is pre-configured to provide customers with a fast time-to-market and easy-to-design solution for high-performance, digitally controlled power supplies with one of ZMDI’s integrated MOSFET power stage DrMOS products: the ZSPM9000, ZSPM9010, ZSPM9015 or ZSPM9060. ZSPM15xx controllers feature a flexible design that allows users to easily select the over-current protection limit, output voltage rise time and control-loop compensation via two external resistors to achieve the highest performance.

ZSPM1513 controllers are preconfigured for the power stage output of 1.2V and capable of supporting up to a maximum load current of 15A. ZMDI provides bills-of-materials and circuit board layouts to improve customer design cycles, reduce external component costs and minimize the application footprint.

“Field programmable gate array (FPGA) and system-on-chip (SoC) applications require multiple voltage supplies to power core and auxiliary rails,” said Hensen Wong, Product Marketing Manager of the ZMDI Power Management Division. “With the introduction of the ZSPM1513 and the wide portfolio of the ZSPM15xx product family, ZMDI offers high precision and easy-to-use turnkey solutions to power the multiple voltage rails in FPGA or SoC based communication and storage applications.”


  • Ultra-fast transient response
  • High accuracy output stage voltage (± 1%)
  • Factory pre-configured with industry-standard voltage: 1.2V
  • Capable of supporting maximum load currents up to 15A
  • Faster time-to-market with tested and ready POL solutions
  • Enhanced performance with ZMDI’s integrated MOSFET power-stage DrMOS products: ZSPM9000, ZSPM9010, ZSPM9015 or ZSPM9060
  • High power density in a 4 x 4 mm QFN24 package
  • Selectable over-current limit protection, output voltage slew rate and control loop compensation
  • Full feature set for fault protection
  • Operation temperature: -40°C to +125°C
  • Operation from a single supply voltage: 5V
  • Pre-configured ZSPM15xx Family of True-Digital PWM Controllers available with additional output voltage options: 0.85V, 1.00V, 1.50V, 1.80V, 2.00V, 2.5V, 3.3V, and 5.00V


  • Powering FPGAs and SoCs core or auxiliary voltage
  • Wireless base stations
  • Enterprise routers/switches
  • Gateways
  • Cloud data storage

    The ZSPM1513 is in full production. Parts and evaluation kits are available from ZMDI ( and its distribution partners (

    About ZMDI
    Zentrum Mikroelektronik Dresden AG (ZMDI) is a global supplier of analog and mixed-signal semiconductors solutions for automotive, industrial, medical, mobile sensing, information technology and consumer applications. These solutions enable our customers to create the most energy-efficient products in sensing, power management and lighting.
    For over 50 years, ZMDI has been globally headquartered in Dresden, Germany. ZMDI serves its customers with sales offices and design centers throughout Germany, Austria, Bulgaria, China, Ireland, Italy, Japan, Korea, Taiwan and the United States.
