Vishay Diode Saves Board Space in Portable Electronics

Vishay released a new bidirectional symmetrical (BiSy) 2-line ESD protection diode in the ultra-compact LLP1006-3L package for portable electronics. Saving space over solutions in the SOT23 Viahay diodes Lpackage, the Vishay Semiconductors VBUS05M2-HT1 offers ultra-low capacitance and leakage current for the protection of high-speed data lines against transient voltage signals.

The device released today combines a low height of < 0.4 mm with low load capacitance of 0.35 pF typical. Featuring a “flow through” design, the VBUS05M2-HT1 is optimized for the protection of high-speed data lines including HDMI, DisplayPort, eSATA, USB 3.0, 1394 / FireWire, and Thunderbolt in smartphones, tablets, notebooks, and wearable devices. The protection diode features a low maximum leakage current of < 0.1 μA at the working voltage of 5.5 V, a breakdown voltage of 8.5 V typical at 1 mA, and a maximum clamping voltage of 18 V at 3.6 A.

The VBUS05M2-HT1 provides transient protection for data lines as per IEC 61000 4 2 at ± 20 kV (air and contact discharge). The device offers a moisture sensitivity level (MSL) of 1 in accordance with J-STD-020 and a UL 94 V-0 flammability rating, and it supports reflow soldering to +260 °C for 10 s. Soldering can be checked by a standard vision inspection, without the need for an X-ray. The protection diode is RoHS-compliant, halogen-free, and Vishay Green.

Samples and production quantities of the VBUS05M2-HT1 are available now, with lead times of eight weeks for large orders.
