Broadband Conicals Provide High DC Current Handling

0

Designer and manufacturer of precision electronic components for broadband radio frequency and power applications, Gowanda Electronics, has announced the introduction of new broadband microwave RF conical inductors that provide DC current handling up to 10 Amps and low insertion loss.

The flying lead series were developed to address market needs and industry trends calling for ever-increasing performance from broadband conical components. Gowanda’s new series will be utilized in communication applications for bias T’s (filter signals, remove noise), broadband chip manufacturing, communication platforms, high frequency, microwave circuitry, RF test set-ups, test and measurement, test gear, test instrumentation and transmission amplifiers.

The performance ranges provided by these four new wirewound conical series include inductance from 0.30 µH to 22 µH (TYP), Q from 30 to 66 (TYP), DCR ohms MAX from 0.02 to 0.265 and current rating mA DC from 1300 to 10500

All four series have been outgassing tested per ASTM E595 and meet the TML requirement of 1.0% max. Operating temperature range is -55°C to +125°C for all series. Standard terminations and gold terminations are RoHS compliant; please contact factory for Pb terminations.

Source Gowanda Electronics
